Have any questions? Let us know! Learn more about Draftsight. UNIT 3 -Isometric Drawing by CAD using any part modeling Software. This process eliminates that slow tedious work by changing your sketch orientation to Isometric, and snapping to the normal angles you’d need and expect is super easy by activating the Ortho snap settings. Relative and Polar), setting of units and layout. Traditionally, I was always taught to sketch isometric views in other 2D CAD programs by calculating the angles and drawing extension lines from the 2D profiles.
For the cube below, it’s just takes switching between 3 easily accessible “planes”. Step 3: Draw! Switching “planes” is as easy as hitting the F5 button on your keyboard. Step 2: Turn on Ortho Snapping (Select the “Ortho” button on the bottom) (RMB on the Grid icon on the bottom, hit Settings, then hit the Isometric radio button under “Orientation”.) Step 1: Switch your grid settings to Isometric. If you are in the process of creating a Draftsight drawing – and need to create a quick isometric view – you can follow the process below: Draftsight Highlights – Easily draw “Isometric Views” within Draftsightĭraftsight is a 2D CAD program, but that doesn’t mean you can’t create an isometric view.
